H 13.9 Terminal Block Connector , Female Right Angle Header Connector

Basic Information
Place of Origin: China
Brand Name: JILN
Certification: UL/CUL/Rosh/SGS
Model Number: JL128R-500(508)XXXX1
Minimum Order Quantity: 500pcs
Price: negotiable
Packaging Details: Tube packing/PE bag packing
Delivery Time: 5-8 days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 8000000Kpcs
Insulator Material:: PA66 Rated Current: 150V,10A
Insulation Temperature: -40℃~+105℃
High Light:

screw terminal block

,

pluggable terminal block

Green Color 5.0 mm H 13.9 Screw Terminal Blocks Female Right Angle

Product description:


Terminal Blocks are used extensively in building wiring for the distribution of electricity - connecting electrical outlets, luminaires and switches to the mains, and for directly connecting major appliances such as clothes dryers and ovens drawing in excess of 15 amperes.



Terminal Blocks are commonly used to connect a chassis ground, such as on a record player or surge protector. Most public address systems in buildings also use them for speakers, and sometimes for other outputs and inputs. Alarm systems and building sensor and control systems have traditionally used large numbers of screw terminations.


Specifications:

Rated Currency: 300V,12A
Dieletric Strength: AC2000V/1 Minute
Insularion Resistance: 500mΩ Min
Contact Resistance: 20mΩ Max
Screw Torque: 0.4Nm(3.5Lb.in)
Wire Range: 24~12AWG
Strip Length: 6-7mm
Term. Range: -40℃~+105℃
Max Solering +250℃.5S
Housing Material: PA66(UL94 V-O)
Contact: Brass, Tin Plating
Clamp: Brass/Steel, NI Plating
Wire Protector: Brass,Ni Plating
Screw: M2.5, Steel, Zinc Plating

JL128R-500(508)XXXX1.pdf



Advantage:


1. High quality.
2. Competitive price.
3. Fast delivery time.
4. Variety models and specifications.
5. Professional manufacturer.

Services:


1. Do not worry, it will be best services.
2. Consult us immediately.
3. We will get back to you the first time.
4. It's my pleasure.



Company Information:



Shenzhen Jinling Electronics Co.,Ltd , Which is Global designer and manufacturer of industry standard and custom connectors,was established 2001 and specialized in manufacturing of precision Board to Board, Wire-to-board connectors,sim card socket, terminal blocks and cable assemblies for computer and all kinds of consumer electronics.We always follow the guideline of specialization and automatization since the establishment.



Our services

1. Specialized in pcb connectors over 15 years.
2. Over 10 years experienced Engineer support OEM&ODM order.

3. All molding stampling,tooling and electroplating processes completed in-house,

4. Fast delivery services help customer satifisfaction rate reach 99%.
5. Cooperation with FCI,Phoniex,Samsung,SIEMENS,PHILPS,OMRON over 5 years.
6. Prompt delivery(3-5 work days),small MOQ(100pcs) .

7. Hight quality,rich experienced,excellent serivce will be your reliable connector solution specialist.

8. Used in the most of home appliances,computer,PCB,LCD,TV
9. Our factory has over decades manufacturing experience.
10. We can provide customers with over 10 sorts and 60,000 different specification connectors parts.



Production Capability:



The factory with area of 20,000 square meters and has about the total number of employees 600 people and owns 30 sets precision mold processing equipment from Taiwan, 34 sets precision plastic injection machine from Taiwan& Japan, as well as 24 sets high –speed precision punch, more than 500 sets various types of plastic molds and more than 240 sets hardware terminal molds,35 sets laboratory testing equipments and over 200 sets machines for automatic assembly that can provide customers with over 10 sorts and 20,000 different specification connectors parts, company handles import-export rights. and up to 40% products are exported to Euro-American countries.

H 13.9 Terminal Block Connector , Female Right Angle Header Connector 0H 13.9 Terminal Block Connector , Female Right Angle Header Connector 1

Complete Testing Equipment:

To provide high quality and best performance -to -price ratio production for customers, we have realized integrated production from plastic and hardware terminals, terminals,plating, design and development of mold, precision plastic ejection and molding and high speed precision hardware punching, to the automatic assembly of products.

H 13.9 Terminal Block Connector , Female Right Angle Header Connector 2

Certifications:

The company main ten series products obtained American UL & CUL certification, with the No. E362810 and No.E472355, E484895(terminal block). All items are in line with EU RoHS and REACH environmental requirements

H 13.9 Terminal Block Connector , Female Right Angle Header Connector 3



FAQ:



Q: What is the MOQ?
A: Our MOQ is: 1000 PCS(1 PCS for sample).

Q: How about samples? is it free ?

A: 20 Piece free sample is available, If you would like to pay the freight fees.

Q: What is your price term & payment terms?

A: 1. Our usual price term is EXW,FOB Shenzhen or FOB Hongkong, but other terms is available too. 2. Payment terms: T/T, Paypal and other terms.

Q: What about your leading&delivery time?

A: Leading time according to your quantity, and usually delivery time is 5~7 working days. If you are very urgent, we can negotiate.

Q: Do you have UL certificate? and others?

A: Of course, we have , and also qualified SGS, ISO9001:2008, ISO14001:2004 etc.

Q: Why choose our company?
A: Professional manufacturer since 2001, provide various kinds of precision cards, connectors and combination cables.

Our MOQ is: 100 PCS(1 PCS for sample).
Good quality, competitive price with best service.
Available for ODM/OEM order.



·Shipping

1. If goods is not large:Fedex .DHL.EMS.UPS,TNT,ect express shipping method.

2. If goods is large:Sea or Air shipping method
