300V 8A Pluggable Pcb Terminal Connector 20mΩ Max Contact Resistance

Basic Information
Place of Origin: China
Brand Name: JILN
Certification: UL/CUL/Rosh/SGS
Model Number: JL15EDGKAM
Minimum Order Quantity: 1000PCS
Price: 0.01-1USD
Packaging Details: Tube packing/PE bag packing
Delivery Time: 7-10 days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 30000000PCS per Month
Insulator Material:: PA66 Rated Current: 300V,8A
Withstand Voltage: 1500V AC/DC Insulation Temperature: -40℃~+105℃
High Light:

screw terminal block

,

pluggable terminal block

Green Color 3.5mm or 3.81mm Pluggable Terminal Blocks

300V 8A Pluggable Pcb Terminal Connector 20mΩ Max Contact Resistance 0

JL15EDGKAM-350(381)XXGX1.pdf



Description



Terminal blocks are used to secure and/or terminate wires and, in their simplest form, consist of several individual terminals arranged in a long strip. Terminals are useful for connecting wiring to a ground or, in the case of electrical power, for connecting electrical switches and outlets to the mains.



Terminal Blocks are used extensively in building wiring for the distribution of electricity - connecting electrical outlets, luminaires and switches to the mains, and for directly connecting major appliances such as clothes dryers and ovens drawing in excess of 15 amperes.



Specifications:


Rated Currency: 300V,8A
Dieletric Strength: AC1500V/1 Minute
Insularion Resistance: 500mΩ Min
Contact Resistance: 20mΩ Max
Screw Torque: -
Wire Range: 28-16AWG
Strip Length: 6-7mm
Term. Range: -40℃~+105℃
Max Solering +250℃.5S
Housing Material: PA66(UL94 V-O)
Contact: Brass, Tin Plating
Clamp: Brass/Steel, NI Plating
Wire Protector: Brass,Ni Plating
Screw: M2.0,Steel,Zinc Plated, Phosphor bronze





We Owned :

1. 20,000 square meters factory, > 600 workers

2. 30 sets precision mold processing equipment

3. 34 sets precision plastic injection machine

4. 24 sets high - speed precision punch

5. 240 sets hardware terminal molds

6. 35 sets laboratory tester

7. > 200 sets machines automatic assemble machine



Company Information:



Jinling Electronics employs exquisite technology from Taiwan,the company was moved to Shenzhen and set up Shenzhen Jinling Electronics Co.,Ltd in 2004.We always follow the guideline of specialization and automatization since its establishment.We have imported advanced production and detecting devices from Japan,Germany and Taiwan.



To provide high quality and best performance-to-price ratio products from customers,we have realized integrated production from the plastic and hardware terminals,design and development of mold,precision plastic ejection molding and high speed precision hardware punching,and automatic assembly of the products,to implementation of one-stop production and service.

300V 8A Pluggable Pcb Terminal Connector 20mΩ Max Contact Resistance 1

Production Capability:



The factory with area of 20,000 square meters and has about the total number of employees 600 people and owns 30 sets precision mold processing equipment from Taiwan, 34 sets precision plastic injection machine from Taiwan& Japan, as well as 24 sets high –speed precision punch, more than 500 sets various types of plastic molds and more than 240 sets hardware terminal molds,35 sets laboratory testing equipments and over 200 sets machines for automatic assembly that can provide customers with over 10 sorts and 20,000 different specification connectors parts, company handles import-export rights. and up to 40% products are exported to Euro-American countries.

300V 8A Pluggable Pcb Terminal Connector 20mΩ Max Contact Resistance 2300V 8A Pluggable Pcb Terminal Connector 20mΩ Max Contact Resistance 3

Complete Testing Equipment:

To provide high quality and best performance -to -price ratio production for customers, we have realized integrated production from plastic and hardware terminals, terminals,plating, design and development of mold, precision plastic ejection and molding and high speed precision hardware punching, to the automatic assembly of products.

300V 8A Pluggable Pcb Terminal Connector 20mΩ Max Contact Resistance 4

Certifications:

The company main ten series products obtained American UL & CUL certification, with the No. E362810 and No.E472355, E484895(terminal block). All items are in line with EU RoHS and REACH environmental requirements

300V 8A Pluggable Pcb Terminal Connector 20mΩ Max Contact Resistance 5



FAQ:



Q: What is the MOQ?
A: Our MOQ is: 1000 PCS(1 PCS for sample).



300V 8A Pluggable Pcb Terminal Connector 20mΩ Max Contact Resistance 6



·Shipping

1. If goods is not large:Fedex .DHL.EMS.UPS,TNT,ect express shipping method.

2. If goods is large:Sea or Air shipping method
