Five Row Female Header DIN 41612 Connector Right Angle Polyester LCP

Basic Information
Place of Origin: China
Brand Name: JILN
Certification: UL/CUL/Rosh
Model Number: 35115160AFRXXBNA1
Minimum Order Quantity: 500pcs
Price: negotiable
Packaging Details: Tube packing/PE bag packing
Delivery Time: 5-8 days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 8000000Kpcs
Insulator Material:: Polyester LCP/PBT Rated Current: 1AMP
Withstand Voltage: 500V AC/Minute Insulation Temperature: -40℃~+105℃
T&R Packing Qty: 1000pcs Contact: Bronze
Original:: China
High Light:

Five Row DIN 41612 Connector


Female Header DIN 41612 Connector


Polyester LCP Right Angle Connector


DIN 41612 Five Row Female Header Right Angle Selective Gold Flash

Contact Rating 3 AMP
Insulator Material PBT
Contact Plating Au or Sn over 50u" Ni
Withstanding Voltage 1000V
Contact Resistance 20Ω Max
Insulation Resistance 1000MΩ Min
Package : Reel packing
Operation Temperature: -40 ℃ to +105 ℃
