Four Row Ejector Male Pin Header Connector Straight Type Current Transmission

Basic Information
Place of Origin: China
Brand Name: JILN
Certification: UL/CUL/Rosh/SGS
Model Number: 3341XXSG0XBLT01
Minimum Order Quantity: 1000pcs
Price: negotiable
Packaging Details: Tube packing
Delivery Time: 7-10 days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 8000000Kpcs
Insulator Material:: Polyester Rated Current: 1.5 AMP
Withstand Voltage: 500V AC/DC Insulation Temperature: -40℃~+105℃
High Light:

pcb header connector

,

surface mount headers

1.27mm Pitch Ejector Header Straight Connector Four Row Gold flash Tube packing


Product description:


Ejector Header are normally only used in combination with insulation-displacement connectors (IDC) for ribbon cables. A notch (key) in the guide EJector header normally prevents placing the connector (polarised by a "bump" on one side) the wrong way around.Ejector header have latch to lock the matching product.



The Ejector header mainly used in communication and electronic equipment and data by welding on the PCB board, connecting the corresponding specifications of IDC cable and other circuit designers need to be welded on a PCB board.


Four Row Ejector Male Pin Header Connector Straight Type Current Transmission 0
Four Row Ejector Male Pin Header Connector Straight Type Current Transmission 1


Specifications:

Contact Material Phosphor Brass
Insulator Material PA6T/PA9T/LCP
Contact Plating Au or Sn over 50U"NI
Withstanding Voltage 500V
Current Rating 1.5A
Insulation Resistance 1000MΩ Min
Package : Tube packing
soldering type Straight
Operation Temperature: -40 ℃ to +105 ℃

3341XXSXXXXLX01(2).pdf



We Owned :

1. 20,000 square meters factory, > 600 workers

2. 30 sets precision mold processing equipment

3. 34 sets precision plastic injection machine

4. 24 sets high - speed precision punch

5. 240 sets hardware terminal molds

6. 35 sets laboratory tester

7. > 200 sets machines automatic assemble machine



Company Information:



Jinling Electronics employs exquisite technology from Taiwan,the company was moved to Shenzhen and set up Shenzhen Jinling Electronics Co.,Ltd in 2004.We always follow the guideline of specialization and automatization since its establishment.We have imported advanced production and detecting devices from Japan,Germany and Taiwan.



we based on the domestic and aiming at the world,Striving to provided customers with high-quality and best-price products.The company has passed the ISO9001:2015quality management system certification and ISO14001:2015 environmental management system certification,IATF 16949 system certification and passed CE certification and TUV certification. Connectors and wires of our company has passed United States UL safety certification.(UL NO.: E362810) and (UL NO.: E472355),terminal blocks(UL NO.:E484895).



Production Capability:



The factory with area of 20,000 square meters and has about the total number of employees 600 people and owns 30 sets precision mold processing equipment from Taiwan, 34 sets precision plastic injection machine from Taiwan& Japan, as well as 24 sets high –speed precision punch, more than 500 sets various types of plastic molds and more than 240 sets hardware terminal molds,35 sets laboratory testing equipments and over 200 sets machines for automatic assembly that can provide customers with over 10 sorts and 20,000 different specification connectors parts, company handles import-export rights. and up to 40% products are exported to Euro-American countries.

Four Row Ejector Male Pin Header Connector Straight Type Current Transmission 2Four Row Ejector Male Pin Header Connector Straight Type Current Transmission 3

Complete Testing Equipment:

To provide high quality and best performance -to -price ratio production for customers, we have realized integrated production from plastic and hardware terminals, terminals,plating, design and development of mold, precision plastic ejection and molding and high speed precision hardware punching, to the automatic assembly of products.

Four Row Ejector Male Pin Header Connector Straight Type Current Transmission 4

Certifications:

The company main ten series products obtained American UL & CUL certification, with the No. E362810 and No.E472355, E484895(terminal block). All items are in line with EU RoHS and REACH environmental requirements

Four Row Ejector Male Pin Header Connector Straight Type Current Transmission 5



FAQ:



Q: What is the MOQ?
A: Our MOQ is: 1000 PCS(1 PCS for sample).

Q: How about samples? is it free ?

A: 20 Piece free sample is available, If you would like to pay the freight fees.

Q: What is your price term & payment terms?

A: 1. Our usual price term is EXW,FOB Shenzhen or FOB Hongkong, but other terms is available too. 2. Payment terms: T/T, Paypal and other terms.

Q: What about your leading&delivery time?

A: Leading time according to your quantity, and usually delivery time is 5~7 working days

Q: Do you have UL certificate? and others?

A: Of course, we have , and also qualified SGS, ISO9001:2008, ISO14001:2004 etc.
