Screw Terminal Block Connector Female JL129C 5.08 Mm Pitch PCB Type

Basic Information
Place of Origin: China
Brand Name: JILN
Certification: UL/CUL/Rosh/SGS
Model Number: JL129C-500(508)XXXX1
Minimum Order Quantity: 500pcs
Price: negotiable
Packaging Details: Tube packing/PE bag packing
Delivery Time: 5-8 days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 8000000Kpcs
Insulator Material:: Polyester PA66 Current: 150V,9.5A
Insulation Temperature: -41℃~+105℃
High Light:

screw terminal block

,

pluggable terminal block

Green Color 5.08 mm Pitch PCB Screw Terminal Blocks Female JL129C

Product description:


Terminal blocks are used to secure and/or terminate wires and, in their simplest form, consist of several individual terminals arranged in a long strip. Terminals are useful for connecting wiring to a ground or, in the case of electrical power, for connecting electrical switches and outlets to the mains.



Terminal Blocks are used extensively in building wiring for the distribution of electricity - connecting electrical outlets, luminaires and switches to the mains, and for directly connecting major appliances such as clothes dryers and ovens drawing in excess of 15 amperes.


Specifications:

Rated Currency: 300V,20A
Dieletric Strength: AC2000V/1 Minute
Insularion Resistance: 500mΩ Min
Contact Resistance: 20mΩ Max
Screw Torque: 0.5Nm(4.4Lb.in)
Wire Range: 24~12AWG
Strip Length: 6-7mm
Term. Range: -40℃~+105℃
Max Solering +250℃.5S
Housing Material: PA66(UL94 V-O)
Contact: Brass, Tin Plating
Clamp: Brass/Steel, NI Plating
Wire Protector: Brass,Ni Plating
Screw: M3.0, Steel, Zinc Plating

JL129C-500(508)XXXX1.pdf



Primary products:



Pin Header Connector

Female Header Connector

Box Header Connector

Ejector Header

Board To Board Connector

DIN 41612 Connector

Flat Ribbon Cable

FFC Cable

Terminal Block Connector

SCSI Connector

Machine Pin Headers

Micro Match Connector

IDC Socket Connector



Features:



High Quality Guaranteed

First Class Service

Best Prices

Stable performance

sturdy and durable

Long lifespan

wear resistant



We are looking forward to long term cooperation with customers, we will make best service and after sales service for all of our customers. If you have any inquiry, please don’t hesitate to contact us. We will reply you at the first time as we can.



Company Information:



Shenzhen Jinling Electronics Co.,Ltd , Which is Global designer and manufacturer of industry standard and custom connectors,was established 2001 and specialized in manufacturing of precision Board to Board, Wire-to-board connectors,sim card socket, terminal blocks and cable assemblies for computer and all kinds of consumer electronics.We always follow the guideline of specialization and automatization since the establishment.



Production Capability:



The factory with area of 20,000 square meters and has about the total number of employees 600 people and owns 30 sets precision mold processing equipment from Taiwan, 34 sets precision plastic injection machine from Taiwan& Japan, as well as 24 sets high –speed precision punch, more than 500 sets various types of plastic molds and more than 240 sets hardware terminal molds,35 sets laboratory testing equipments and over 200 sets machines for automatic assembly that can provide customers with over 10 sorts and 20,000 different specification connectors parts, company handles import-export rights. and up to 40% products are exported to world wide.

Screw Terminal Block Connector Female JL129C 5.08 Mm Pitch PCB Type 0Screw Terminal Block Connector Female JL129C 5.08 Mm Pitch PCB Type 1

Complete Testing Equipment:

To provide high quality and best performance -to -price ratio production for customers, we have realized integrated production from plastic and hardware terminals, terminals,plating, design and development of mold, precision plastic ejection and molding and high speed precision hardware punching, to the automatic assembly of products.

Screw Terminal Block Connector Female JL129C 5.08 Mm Pitch PCB Type 2

Certifications:

The company main ten series products obtained American UL & CUL certification, with the No. E362810 and No.E472355, E484895(terminal block). All items are in line with EU RoHS and REACH environmental requirements

Screw Terminal Block Connector Female JL129C 5.08 Mm Pitch PCB Type 3



FAQ:



Q: What is the MOQ?
A: Our MOQ is: 1000 PCS(1 PCS for sample).

Q: How about samples? is it free ?

A: 20 Piece free sample is available, If you would like to pay the freight fees.

Q: What is your price term & payment terms?

A: 1. Our usual price term is EXW,FOB Shenzhen or FOB Hongkong, but other terms is available too. 2. Payment terms: T/T, Paypal and other terms.

Q: What about your leading&delivery time?

A: Leading time according to your quantity, and usually delivery time is 5~7 working days. If you are very urgent, we can negotiate.

Q: Do you have UL certificate? and others?

A: Of course, we have , and also qualified SGS, ISO9001:2008, ISO14001:2004 etc.

Q: Why choose our company?
A: Professional manufacturer since 2001, provide various kinds of precision cards, connectors and combination cables.

Our MOQ is: 100 PCS(1 PCS for sample).
Good quality, competitive price with best service.
Available for ODM/OEM order.



·Shipping

1. If goods is not large:Fedex .DHL.EMS.UPS,TNT,ect express shipping method.

2. If goods is large:Sea or Air shipping method
