| Place of Origin: | China |
|---|---|
| Brand Name: | JILN |
| Certification: | UL/CUL/Rosh/SGS |
| Model Number: | JL350-396XXGX1 |
| Minimum Order Quantity: | 500pcs |
| Price: | negotiable |
| Packaging Details: | Tube packing/PE bag packing |
| Delivery Time: | 5-8 days |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 8000000Kpcs |
| Insulator Material:: | PA66 | Rated Current: | 150V,10A |
|---|---|---|---|
| Reference Temperature: | -40℃~+105℃ | ||
| High Light: | pcb terminal connector,pluggable terminal block |
||
Green Color 3.96 mm Pitch PCB Screw Terminal Blocks Female JL350
| Rated Currency: | 300V,10A |
| Dieletric Strength: | AC1250V/1 Minute |
| Insularion Resistance: | 500mΩ Min |
| Contact Resistance: | 20mΩ Max |
| Screw Torque: | 0.2Nm(1.7Lb.in) |
| Wire Range: | 24~18AWG |
| Strip Length: | 5-6mm |
| Term. Range: | -40℃~+105℃ |
| Max Solering | +250℃.5S |
| Housing Material: | PA66(UL94 V-O) |
| Contact: | Brass, Tin Plating |
| Clamp: | Brass/Steel, NI Plating |
| Wire Protector: | Brass,Ni Plating |
| Screw: | M2.0, Steel, Zinc Plating |
Company Information:
Shenzhen Jinling Electronics Co.,Ltd ,was established in 2001, Which is Global designer and manufacturer of industry standard and custom connectors,was established 2001 and specialized in manufacturing of precision Board to Board, Wire-to-board connectors,sim card socket, terminal blocks and cable assemblies for computer and all kinds of consumer electronics.We always follow the guideline of specialization and automatization since the establishment.
To provide high quality and best performance-to-price ratio products from customers,we have realized integrated production from the plastic and hardware terminals,design and development of mold,precision plastic ejection molding and high speed precision hardware punching,and automatic assembly of the products,to implementation of one-stop production and service.
Production Capability:
The factory with area of 20,000 square meters and has about the total number of employees 600 people and owns 30 sets precision mold processing equipment from Taiwan, Our machine from Taiwan& Japan, as well as 24 sets high –speed precision punch, more than 500 sets various types of plastic molds and more than 240 sets hardware terminal molds,35 sets laboratory testing equipments and over 200 sets machines for automatic assembly that can provide customers with over 10 sorts and 20,000 different specification connectors parts,
Complete Testing Equipment:
To provide high quality and best performance -to -price ratio production for customers, we have realized integrated production from plastic and hardware terminals, terminals,plating, design and development of mold, precision plastic ejection and molding and high speed precision hardware punching, to the automatic assembly of products.
Certifications:
The company main ten series products obtained American UL & CUL certification, with the No. E362810 and No.E472355, E484895(terminal block). All items are in line with EU RoHS and REACH environmental requirements
FAQ:
Q: What is the MOQ?
A: Our MOQ is: 1000 PCS(1 PCS for sample).
Q: How about samples? is it free ?
A: 20 Piece free sample is available, If you would like to pay the freight fees.
Q: What is your price term & payment terms?
A: 1. Our usual price term is EXW,FOB Shenzhen or FOB Hongkong, but other terms is available too. 2. Payment terms: T/T, Paypal and other terms.
.
·Shipping
1. If goods is not large:Fedex .DHL.EMS.UPS,TNT,ect express shipping method.
2. If goods is large:Sea or Air shipping method
