|Current Rating:||1.5AMP||Operating Temperature:||-40℃ To+105℃|
High Flatness PCB Header Connector,
Triple Row PCB Header Connector,
1.5AMP Right Angle Pin Header
0.8*1.2mm Board Spacer Dual Row SMT
2.00mm Pin Header Triple Row Straight Right Angle
Jinling Electronics employs exquisite technology from Taiwan,the company was moved to Shenzhen and set up Shenzhen Jinling Electronics Co.,Ltd in 2004.We always follow the guideline of specialization and automatization since its establishment.We have imported advanced production and detecting devices from Japan,Germany and Taiwan.
1. Rated Current: 1.5AMP
2. Contact Resistance: 20mΩ Max
3. Withstand Voltage: 500V AC/DC
4. Insulation Resistance: 1000mΩ Min
5. Operation Tempature: -40℃-+105℃
6. Contact Material: Brass
7. Contact Plating: Au or Sn over 50 u" Ni
8. Insulator Material: Polyester(UL94V-0)
9. Stand: PA6T
10. Max.Processing Temp: 230℃ for 20-30 Seconds(260℃ for 10 Seconds)
To provide high quality and best performance-to-price ratio products from customers,we have realized integrated production from the plastic and hardware terminals,design and development of mold,precision plastic ejection molding and high speed precision hardware punching,and automatic assembly of the products,to implementation of one-stop production and service.
we based on the domestic and aiming at the world,Striving to provided customers with high-quality and best-price products.The company has passed the ISO9001:2015quality management system certification and ISO14001:2015 environmental management system certification,IATF 16949 system certification and passed CE certification and TUV certification. Connectors and wires of our company has passed United States UL safety certification.(UL NO.: E362810) and (UL NO.: E472355),terminal blocks(UL NO.:E484895).
The factory with area of 20,000 square meters and has about the total number of employees 600 people and owns 30 sets precision mold processing equipment from Taiwan, 34 sets precision plastic injection machine from Taiwan& Japan, as well as 24 sets high –speed precision punch, more than 500 sets various types of plastic molds and more than 240 sets hardware terminal molds,35 sets laboratory testing equipments and over 200 sets machines for automatic assembly that can provide customers with over 10 sorts and 20,000 different specification connectors parts, company handles import-export rights. and up to 40% products are exported to Euro-American countries.
Complete Testing Equipment:
To provide high quality and best performance -to -price ratio production for customers, we have realized integrated production from plastic and hardware terminals, terminals,plating, design and development of mold, precision plastic ejection and molding and high speed precision hardware punching, to the automatic assembly of products.
The company main ten series products obtained American UL & CUL certification, with the No. E362810 and No.E472355, E484895(terminal block). All items are in line with EU RoHS and REACH environmental requirements
Q: What is the MOQ?
A: Our MOQ is: 1000 PCS(1 PCS for sample).
Q: What is your price term & payment terms?
A: 1. Our usual price term is EXW,FOB Shenzhen or FOB Hongkong, but other terms is available too. 2. Payment terms: T/T, Paypal and other terms.
Q: What about your leading&delivery time?
A: Leading time according to your quantity, and usually delivery time is 5~7 working days
